Wall-Mounted Fume Extractor Exhaust Arms and Fume Extractor Arms For laboratory fittings
Features of Wall Mounted Fume Extractors:
1. Joint: made of high density polypropylene PP material, easy to disassemble, restructuring and cleaning.
2. Joint sealing ring: the anti-aging high-density rubber.
3. Articular tension knob: high density PP material.
4. Flow regulating valve: combined with circular connector designed for manual adjustment, through an external valve knob, adjust the angle valve to control into the gas flow.
5. In gas-collecting Hood: PP white/red/transparent.
6. Telescopic tube: ￠ 75mm PVC/PP
7. Joint colour: white/red
Descriptions of Wall Mounted Fume Extractors:
1. A four-section telescopic tube, gas-collecting hood, mount, and other components.
2. Size: ① diameters: ф 75mm; ②the total length (in four sections): 1500mm.
3. Material: ① tube: PP pipe; ② rotary joint: ③ connecting rod Joint Center: galvanized steel ; ④ support spring: plating zinc steel ⑤ joint gasket: low friction ring rubber gasket; ⑥ articular tension knob: PP; sadly, solar Butterfly;Valves: plastic (outer edge by the soft treatment).
4. Gas-collecting hood of ф 310mm.
5. Exhaust hood ventilation volume is adjustable, you can shut down when not.
6. Surface wind velocity ≥ 0.35 m/s, exhaust 200m3/h.
7. Built-in manual balancing valves, adjustable exhaust flue gas back up and avoid, wrong drug and environmental pollution; the connection parts tight lock fixed, no shaking, has good air tightness;
8. After securing device implementation does not sag requirements, achieve a straightened horizontally.Direction can also ensure not pendulous;
9. Overall demolition equipment is convenient, easy to clean, non-hygienic dead angle.
Specification
| Joint: | High grade PP, to be 360° swiveled, dismantled & assembled easily for cleaning |
| Guiding ring: | PP |
| Center bolt: | 304 stainless steel |
| Adjustable joint knob: | High grade PP with a molded-in s/s bearing lockingf with center bolt |
| Damper: | To manually adjust air flow with a knob, |
| Dome/hood: | Red/White/Semi transparent/Full transparent |
| Tube: | Φ100mm, PP |
| 360° swing device: | Enabling movement radius to max.1200mm/1500mm/1800mm/2100mm/2400mm |
| Installation Bracket: | Cold rolled steel with powder coated |
